MPO/MTP Cassette
SHENZHEN GRACYFIBER TECHNOLOGY Co.,LTD Gracyfiber provides a complete fiber optic cabling solution, utilizing all standard connectors and cable formats to provide high-quality and reliable fiber optic solutions. The Gracyfiber solution includes a range of connectors, adapters, pigtails, and...
- Product Introduction
Gracyfiber provides a complete fiber optic cabling solution, utilizing all standard connectors and cable formats to provide high-quality and reliable fiber optic solutions. The Gracyfiber solution includes a range of connectors, adapters, pigtails, and jumpers. We also offer a one-stop shop approach, allowing our customers to integrate the purchase of accessories, active and passive optical products.
Professional team
We focus on active optical transceivers and passive product lines for cables, equipment, and modules. We are willing to customize and bring reliable solutions for the next generation of networks in the telecommunications and data communication fields.
One stop service
Customers can integrate the purchase of accessories, active and passive optical products.
2014Year
Establishment time
4000+m²
Company area
160+People
Number of employees
10+Year
R&D time
Why did you choose our company?
We always adhere to a principle that only through practice and innovation can we continuously move forward. Practice is the foundation of everything, and innovation is the driving force for progress. The two are combined, and only by constantly advancing through practice and innovation can we truly make good products.
high quality
Advanced Equipment
Professional Team
One-Stop Solution
Comprehensive R&D System
Our company has gathered numerous product R&D engineers with over ten years of experience in the field of optical communication, covering the entire process from product design, verification, testing to final delivery.
Systematic talent cultivation mechanism
We adhere to the concept of "people-oriented" and are committed to implementing long-term talent cultivation strategies to ensure that the personal development of employees is synchronized with the company's goals.
High quality scenario based solutions
For different scenarios such as operators, data centers, financial enterprises, and education, we provide diversified product solutions to meet various professional needs.
Excellent service system
We promise to provide customers with comprehensive high-quality pre-sales and after-sales services, ensuring continuous optimization of customer experience.
Certifications
We have numerous invention patents and numerous professional certifications
Patent certificate
Patent certificate
Patent certificate
System certification
System certification
Copyright certificate
Our Pre sales service
Professional, serious, responsible, patient, and friendly
01
Deep technical knowledge reserves and rich practical experience
We always prioritize customer needs and provide customized solutions to ensure effective communication and feasibility of solutions. Our service is full of enthusiasm, and we believe that professionalism, efficiency, and enthusiasm are the key to winning customer trust.
02
Pay attention to details and personalized service
In deep communication with customers, we carefully listen to their needs, analyze actual problems carefully, and tailor the most suitable solution. We believe that only by deeply understanding our customers can we provide them with truly valuable services.
03
The importance of speed and timeliness
When customers encounter problems or needs, we always respond as quickly as possible and quickly solve their problems. Time is very precious to our customers, so we are always committed to providing timely and efficient services to make them feel our dedication and professionalism.
Our after-sales service
We are committed to providing you with a high-quality experience with our fast response ability, experienced team, regular communication, and active listening as our core. We can not only quickly solve problems, but also regularly communicate with you, listen to your opinions, continuously improve ourselves, and ensure that you receive the best service experience.
Positive and prompt response
We promise that no matter what problems you encounter, we will respond and provide solutions as quickly as possible. Our goal is to provide you with a seamless and smooth experience during use.
Experienced team support
Our team not only possesses rich professional knowledge, but also has extensive practical experience. Can quickly locate the problem and provide feasible solutions. Compared to other companies, our team is more professional and reliable, and can provide you with meticulous support.
Regular communication
We will regularly communicate with you to understand your experience with the product, collect your feedback, and promptly resolve any potential issues. We believe that through continuous communication and improvement, we can provide you with more perfect products and services.
Active Listening
We always listen to your opinions and needs. We have carefully considered your suggestions and are striving to improve our service quality. Compared to other companies, we place more emphasis on interaction and communication with customers, making our services more considerate.
Product introduction
MTP/MPO Cassette fiber optic cassette is a convenient plug and play fiber optic cable management solution that can improve the manageability of wiring.
quality assurance
Each MTP/MPO cartridge will undergo factory termination pre installation and factory testing of 12 or 24 fiber MTP/MPO components to ensure the quality of optical loss performance.
MTP/MPO Box Compatibility
The MTP/MPO cassette can be flexibly integrated into Optec's rack mounted distribution board for fast installation and reliable fiber optic cable management.
Customized fiber core quantity
Meanwhile, each MPO/MTP cassette supports different numbers of fiber cores, which can be determined according to the user's needs.
Flexible replacement of connectors
We also support replacing different numbers of connectors and connectors to meet the needs of different projects.
comparison of product parameters
| Product types | Fiber optic connection equipment | Product specifications | 120-116-32/102-116-32/118-88-35, etc |
| Number of fiber optic cores | 12 core,24core,etc | Fiber type | Single mode OS2 9/125 μ m |
| Front end connector | LC/UPC /APC/duplex | Backend connector | MTP /MPO |
| MTP ® adapter | Key up-Key down | Fiber optic grade | Corning SMF-28 fiber optic |
| Material of connector core | Zirconia ceramics | Box material | Aluminum (AL5052) |
| insertion loss | MTP ≤ 0.35dB, LC≤0.2dB | Return loss | MTP ≥ 60dB, LC≥50dB |
| working temperature | -10 ℃~+60 ℃ | Storage temperature | -10 ℃~+60 ℃ |
Our product advantages
High density and easy to plug box modules:
Each 1U can accommodate up to 96 optical fibers, and each 4U rack mounted distribution board can accommodate 384 optical fibers, providing excellent wiring capacity and flexibility.
Plug and play MTP/MPO cabling solution:
Perfectly integrated with Optec rack mounted distribution boards, easy to achieve fast configuration and networking.
Easy to install:
Each port is equipped with channel labels and data labels for insertion loss values, ensuring a simple and accurate installation process.
Easy to use and install:
The rear is pre installed with fiber optic MTP/MPO adapters, and the front panel is equipped with LC adapters, making it simple and convenient to use.
Beyond standard performance:
Our products meet or even exceed the performance standards of TIA/EIA and IEC, ensuring excellent performance through factory pre installed and tested MTP/MPO to LC hydraulic components.
Eliminate on-site terminals and improve efficiency:
By reducing labor costs and improving wiring management capabilities, our products can significantly improve your work efficiency and cost-effectiveness.
Compared to peers
The advantage compared to peers is what truly moves customers
High quality and high requirements:
100% pre terminated and tested at the factory to ensure transmission performance. Quick configuration and networking, reducing installation time. Supports 40G and 100G network applications.
High performance and reliability:
Our products meet or even exceed industry standards, ensuring the performance and reliability of each component through factory pre installation and testing.
Flexible customized services:
We provide customized services to customers, customizing solutions based on their needs and specific scenarios to meet different needs.
Comprehensive solution:
We not only provide products, but also comprehensive solutions, including design, deployment, training, and support services, to provide customers with a one-stop service.
Introduction to product application scenarios
Our product has a wide range of usage scenarios
Data center
The MPO/MTP series products can be applied in places with high data transmission volumes in data centers. By using MPO/MTP cassettes, we can greatly reduce the use of jumpers. At the same time, taking advantage of the fast transmission speed and wide bandwidth of MPO/MTP, we can achieve low latency and high-speed data transmission.
data transmission
With the rapid development of AI, the amount of data transmission is increasing, and the required bandwidth for data transmission is also increasing, MPO/MTP, due to its high speed, large bandwidth, and multi-channel characteristics, can meet the current requirements for transmitting large amounts of data.
5G Network
With the development of the times, 5G networks are developing rapidly, with higher network transmission speeds and lower latency. Traditional network transmission media are no longer able to support high speed and large bandwidth transmission needs. MPO/MTP cassette, as a new type of transmission device, has the characteristics of high speed, large bandwidth, and ease of use, which can fully meet the needs of 5G networks.
metropolitan area network
In the current era of urban joint development, the connection between cities is becoming increasingly close, and the amount of data exchanged is also increasing. In the context of such a large amount of data transmission, MPO/MTP products have emerged. Using MPO/MTP products not only meets the needs of transmitting large amounts of data, but also reduces the use of jumpers. By integrating multiple data channels and sending them together, it can improve utilization and save resources.
Core solution:
25G Trunk Cabling Solution
In 10G trunk wiring, A-type and AF MTP fiber optic boxes are used in pairs. One is deployed in a rack mounted fiber optic cabinet, and the other is installed in a wall mounted fiber optic cabinet. This applies to backbone cabling, security monitoring cabling, and campus networks.
Solution advantages
We will provide you with the best solution service
Supporting a large number of channels
We provide 8-96 channels of data access based on the detailed needs of customers and project requirements, and we also support access with a maximum of 96 channels.
Quick deployment
Our MPO/MTP products are designed to be simple and user-friendly, allowing for quick deployment in a short period of time, helping customers achieve project goals more quickly.
Excellent transmission speed and parameter control
Our solution excels in speed transmission and can transmit at high speeds. At the same time, our MPO/MTP cassette has excellent insertion loss control, which can improve the stability of the transmission network.
More diverse product combination methods
Our products can be highly customizable, supporting a wider range of device types and a wider range of combination methods, which can provide targeted solutions for many application scenarios.
Everything You Need to Know
A series of questions about MTP/MPO cassettes
What is the difference between Type A and Type B MPO?
Type A MPO adapters all have a key up on one side and the mating connector key down on the other side. Type B trunk cable uses key up connector on both ends. This type of array mating results in an inversion, which means the fiber positions are reversed at each end.
What role does the cassette play in cabling?
In cabling management, the cassette can provide multiple LC fiber ports with only one box structure, which is a convenient and effective wiring method.
The advantages of MPO distribution boxes in high-density fiber optic applications?
MPO distribution boxes can effectively manage a large number of fiber optic connections, making wiring cleaner and more efficient.
They provide a simple way to connect a large number of optical fibers, reducing installation and maintenance time and costs.
Due to its modular design, The MPO distribution box can flexibly adapt to different network configurations and requirements.
The impact of inversion between Type A and Type B MPO on fiber optic connections?
Inversion can cause the fiber optic position to be reversed, which may cause optical signal errors during connection.
If the Type A and Type B MPO connectors are not correctly matched, it may lead to connection failure or data transmission issues.
The design principle of MPO distribution box?
The design of the MPO distribution box is based on the modular concept, which includes one or more MPO/MTP connectors, as well as a corresponding number of LC or SC connectors.When the fiber optic backbone cable is inserted through the MPO connector, The optical fibers inside the MPO distribution box will be converted to LC or SC connectors to achieve fiber optic connections.
The most suitable situation for using MPO distribution boxes is?
When a large number of optical fibers need to be connected and space is limited, The MPO distribution box is an ideal choice.
In scenarios such as data centers, data centers, and enterprise networks that require high-density fiber optic cabling, The MPO distribution box is particularly suitable.
Installation and maintenance precautions for MPO distribution box?
When installing the MPO distribution box, ensure that the connectors are correctly aligned and inserted into place to avoid damaging the fiber optic or connectors.
Regularly check the connection status of the MPO distribution box to ensure stable and reliable connection.
If any connection issues are found, clean the connectors or replace damaged components in a timely manner to ensure the quality of fiber optic transmission.
What are the differences between MPO distribution boxes and ordinary fiber optic connection boxes?
MPO distribution boxes typically have higher port density and can accommodate more fiber optic connections.
They typically adopt a modular design that allows for easy expansion and management of a large number of fiber optic connections.
MPO distribution boxes are usually suitable for high-density fiber optic cabling environments, such as data centers and enterprise networks, while ordinary fiber optic connection boxes are more suitable for smaller scale cabling needs.
